Company Name:The Douthitt Company
| DMX Exposure Unit | | Company: The Douthitt Company Click to view Company WebSite | |
Complete 5000 Watt Metal Halide Printing Lamp Assembly.
Glass down design. Simply load, close, expose.
No limit to height of screen because of special Douthitt “Deep Draw” Black Blanket. Under vacuum, this blanket swiftly molds itself to the shape of the screen frame and holds your positive in perfect contact.
Douthitt Heavy Duty Model Magic 83 - 10 memory combination light integrator and digital timer.
Completely automatic operation. Vacuum delay and light exposure activated by closing the frame.
Cooling fans to insure against excessive heat build-up.
Heavy duty pump and motor.
Instrument panel conveniently mounted on side of unit.
All heavy gauge metal construction.
Large convenient access door on left side of unit.
OPTIONAL ACCESSORIES:
(A) Douthitt Heavy Duty Model 26 Silent Air Pumps instead of standard pump and motor (this pump requires compressed air). For Details.
(B) 8000 Watt Metal Halide Printing Lamp assembly instead of standard lamp. |
(Click Image for Larger View) |
| DMH Exposure Unit | | Company: The Douthitt Company Click to view Company WebSite | |
Complete 5000 Watt Metal Halide Printing Lamp Assembly.
Glass down design. Simply load, close, expose.
No limit to height of screen because of special Douthitt “Deep Draw” Black Blanket. Under vacuum, this blanket swiftly molds itself to the shape of the screen frame and holds your positive in perfect contact.
Douthitt Heavy Duty Model Magic 83 - 10 memory combination light integrator and digital timer.
Completely automatic operation. Vacuum delay and light exposure activated by closing the frame.
Cooling fans to insure against excessive heat build-up.
Heavy duty pump and motor.
Instrument panel conveniently mounted on side of unit.
All heavy gauge metal construction.
Large convenient access door on left side of unit.
OPTIONAL ACCESSORIES:
(A) Douthitt Heavy Duty Model 26 Silent Air Pumps instead of standard pump and motor (this pump requires compressed air). For Details.
(B) 8000 Watt Metal Halide Printing Lamp assembly instead of standard lamp.
|
(Click Image for Larger View) |
| DMZ-T Exposure Unit | | Company: The Douthitt Company Click to view Company WebSite | |
Complete 2300 Watt Metal Halide Printing Lamp Assembly.
Glass down design. Simply load, close, expose.
No limit to height of screen because of special Douthitt “Deep Draw” Black Blanket. Under vacuum, this blanket swiftly molds itself to the shape of the screen frame and holds your positive in perfect contact.
Douthitt Heavy Duty Model Magic 83 - 10 memory combination light integrator and digital timer.
Completely automatic operation. Vacuum delay and light exposure activated by closing the frame.
Cooling fans to insure against excessive heat build-up.
Heavy duty pump and motor.
Instrument panel conveniently mounted on side of unit.
All heavy gauge metal construction.
Large convenient access door on left side of unit.
OPTIONAL ACCESSORIES:
(A) Douthitt Heavy Duty Model 26 Silent Air Pumps instead of standard pump and motor (this pump requires compressed air). For Details.
(B) 5000 Watt Metal Halide Printing Lamp assembly instead of standard lamp. |
(Click Image for Larger View) |
| DMZ Exposure Unit | | Company: The Douthitt Company Click to view Company WebSite | | MODEL DMA Safe - No exposed printing rays! Flexible - No limit on depth of screen! Simple to Operate - Load - Close - Expose. Price Includes:
Complete 2300 Watt Metal Halide Printing Lamp Assembly. Shorter exposures, pollution free and longer bulb life with no fall off! This lamp is the ideal light source for screen type emulsions.
Exclusive glass down design. Simply load, close and expose.
No limit to height of screen because of special DOUTHITT "DEEP DRAW" BLACK Blanket. Under vacuum this blanket swiftly molds itself to the shape of the screen frame and holds your positive in perfect contact. The Blanket is secured to structural steel tubing and the blanket frame is raised and lowered by exclusive sliding toggle.
Heavy Duty Vacuum Pump and Motor.
Cooling fans to insure against excessive heat build up.
Heavy Optic clear A-1 Select Glass anchored to structural steel tubing to withstand pressure of the heaviest screen frame under vacuum.
Heavy Duty Digital Automatic Reset Timer.
Built in safety features:
The shutter on the lamp cannot be opened when the blanket frame is in a raised position.
When the front access door is opened all power is cut off.
Instrument panel conveniently mounted on side of unit with the following:
Vacuum Switch
Vacuum Gauge
Digital Timer
Bleeder Valve
All Heavy Gauge Metal Construction.
Unit finished in easy to clean, long wearing Epoxy Enamel.
Vacuum automatically cancels after exposure.
OPTIONAL ACCESSORIES:
5000 Watt Metal Halide Printing Lamp Assembly instead of standard lamp.
Douthitt Heavy Duty Model 26 Silent Air Pump instead of standard pump & motor (this pump requires compressed air).For Details.
Douthitt Heavy Duty Model MAGIC 83 Combination Light Integrator and Digital Timer in lieu of Timer. Integrator comes complete with vacuum time delay for one button automation.For Details.
|
(Click Image for Larger View) |
| DMA Exposure Unit | | Company: The Douthitt Company Click to view Company WebSite | |
Complete Metal Halide Printing Lamp Assembly.
Douthitt Heavy Duty Model MAGIC 83 Combination Light Integrator and Digital Timer complete with 10 memories.
No limit to height of screen because of special DOUTHITT “DEEP DRAW” BLACK Blanket. Under vacuum, this blanket swiftly molds itself to the shape of the screen frame and holds your positive in perfect contact.
Heavy Duty Vacuum Pump and Motor.
Vacuum Relief Bleeder Valve.
Loads Glass Down.
Effortless raising and lowering of the blanket frame.
All Heavy Gauge Welded Construction.
Bottom and Back are left open to facilitate cooling.
|
(Click Image for Larger View) |
|
